LEOCompact and versatile, our adaptable model
Previous
Next
LEO is a multi-purpose traction machine for installations with duty load up to 630 kg (1/1 roping ratio) or up to 1000 kg (2/1 roping ratio). Vertical or horizontal configuration, with right- or left-hand sheave. The worm screw axis is inclined. The motor and brake can be positioned as required.
LEO is also available in the version with drum and remote emergency operating system.
Specifications
Sheaves
Photos and details
Specifications
Features |
Unit of measurement |
Value |
|---|---|---|
Maximum static load |
kg |
3.000 |
Ratio |
n°/n° |
1/71 – 1/55 – 1/45 – 2/71 – 2/57 – 3/47 |
Roping |
n°/n° |
1/1 – 2/1. |
Duty load |
kg |
up to 630 kg Roping 1/1; up to 1.000 kg Roping 2/1. |
Sheave speed |
m/s |
0.18 – 4.21 |
Regulation |
– |
4/16 – VF |
Power range 4/16 poles |
kW sinc |
3,5 -> 5,5 |
Power range VF 4 poles
|
kW sinc |
3,3 -> 11 |
Moment of inertia J
with AC2 motor |
Kgm² |
0,371 – 0,488 |
Moment of inertia J
with VF motor |
Kgm² |
0,046 – 0,171 |
Oil capacity |
– |
lubricated for life
|
